Testing your Ansible roles with Molecule

After the announcement on September 26 that Ansible will be adopting molecule and ansible-lint as official 'Ansible by Red Hat' projects, I started moving more of my public Ansible projects over to Molecule-based tests instead of using the homegrown Docker-based Ansible testing rig I'd been using for a few years.

Molecule sticker in front of AnsibleFest 2018 Sticker

There was also a bit of motivation from readers of Ansible for DevOps, many of whom have asked for a new section on Molecule specifically!

In this blog post, I'll walk you through how to use Molecule, and how I converted all my existing roles (which were using a different testing system) to use Molecule and Ansible Lint-based tests.

Installing Molecule

Assuming you have pip installed, Installing Molecule is quite easy:

pip install molecule

Check if it's working:

$ molecule --version
molecule, version 2.19.0

Initializing a new role with Molecule

Before we start integrating Molecule into an existing role, let's take a look at the 'happy path'—using Molecule itself to init a new role:

molecule init role -r geerlingguy.example -d docker

This command uses ansible-galaxy behind the scenes to generate a new Ansible role, then it injects a molecule directory in the role, and sets it up to run builds and test runs in a docker environment. Inside the Molecule directory is a default directory, indicating the default test scenario. It contains the following:

$ cd geerlingguy.example/molecule/default/ && ls
Dockerfile.j2
INSTALL.rst
molecule.yml
playbook.yml
tests

Here's a quick rundown of what all these files are:

  • Dockerfile.j2: This is the Dockerfile used to build the Docker container used as a test environment for your role. You can customize it to your heart's content, and you can even use your own Docker image instead of building the container from scratch every time—I'll cover how to do that later though. The key is this makes sure important dependencies like Python, sudo, and Bash are available inside the build/test environment.
  • INSTALL.rst: Contains instructions for installing required dependencies for running molecule tests.
  • molecule.yml: Tells molecule everything it needs to know about your testing: what OS to use, how to lint your role, how to test your role, etc. We'll cover a little more on this later.
  • playbook.yml: This is the playbook Molecule uses to test your role. For simpler roles, you can usually leave it as-is (it will just run your role and nothing else). But for more complex roles, you might need to do some additional setup, or run other roles prior to running your role.
  • tests/: This directory contains a basic Testinfra test, which you can expand on if you want to run additional verification of your build environment state after Ansible's done its thing.

You can customize and/or remove pretty much everything. In many of my roles, I use a custom pre-made Docker image which already has Python and Ansible, so I removed the Dockerfile.j2 template, and updated the image in my molecule.yml to point to my public Docker Hub images. You can also use environment variables anywhere inside the molecule.yml file, so you could have an environment variable like MOLECULE_IMAGE and specify a different OS base image whenever you do a test run, without adding additional scenarios (besides default).

I also use Ansible itself (usually the uri, assert, and fail modules mostly) to do functional tests after the playbook.yml runs, so I delete the tests/ directory, and Molecule automatically detects there are no test infra tests to run.

Running your first Molecule test

Your new example role doesn't have anything exciting in it yet, but it should—at this point—pass all tests with flying colors! So let's let Molecule do its thing:

$ cd ../../
$ molecule test
...
--> Validating schema /Users/jgeerling/Downloads/geerlingguy.example/molecule/default/molecule.yml.
Validation completed successfully.
--> Test matrix

└── default
    ├── lint
    ├── destroy
    ├── dependency
    ├── syntax
    ├── create
    ├── prepare
    ├── converge
    ├── idempotence
    ├── side_effect
    ├── verify
    └── destroy

--> Executing Yamllint on files found in /Users/jgeerling/Downloads/geerlingguy.example/...
Lint completed successfully.
--> Action: 'syntax'
    playbook: /Users/jgeerling/Downloads/geerlingguy.example/molecule/default/playbook.yml
--> Action: 'converge'
--> Action: 'idempotence'
Idempotence completed successfully.
...

After a couple minutes, Molecule runs through all the testing steps: linting, checking playbook syntax, building the Docker environment, running the playbook in the Docker environment, running the playbook again to verify idempotence, then cleaning up after itself.

This is great! You can work on the role, and then whenever you want, run molecule test and verify everything still passes.

But what about development? Molecule is actually great for that too!

Role development with Molecule

I used to use this Ansible role testing 'shim' script to do lightweight development of my roles, but it was a little bit of a hassle using it, and I didn't have a quick "build me a local environment to work in and leave it running" mode, without setting some extra environment variables.

With Molecule, any time you want to bring up a local environment and start running your role, you just run molecule converge. And since you can use Molecule with VirtualBox, Docker, or even AWS EC2 instances, you can have your role run inside any type of virtual environment you need! (Sometimes it can be hard to test certain types of applications or automation inside of a Docker container).

So my new process for developing a role (either a new one, or when fixing or improving an existing role) is:

molecule init role -r geerlingguy.example -d docker
molecule converge
<do some work on the role>
molecule converge
<see that some changes didn't work>
molecule converge
<see everything working well, commit my changes>
molecule converge
<idempotence check - make sure Ansible doesn't report any changes on a second run>
molecule destroy

It's a lot more fun and painless to work on my roles when I can very quickly get a local development environment up and running, and easily re-run my role against that environment over and over. The faster I can make that feedback cycle (make a change, see if it worked, make another change...), the more—and higher quality—work I can get done.

The converge command is even faster after the first time it's run, as the container already exists and doesn't have to be created again.

Also, when I get a build failure notification from Travis CI, I can just cd into the role directory, run molecule test, and quickly see if the problem can be replicated locally. I used to have to set a few environment variables (which I would always forget) to reproduce the failing test locally, but now I have a more efficient—and easy to install, via pip install molecule—option.

Configure Molecule

If you've been working through the examples in this blog post, you'll notice Molecule puts out a lot of notices about skipped steps, like:

--> Action: 'dependency'
Skipping, missing the requirements file.
--> Scenario: 'default'
--> Action: 'create'
Skipping, instances already created.
--> Scenario: 'default'
--> Action: 'prepare'
Skipping, prepare playbook not configured.

What if you want to customize the order of tasks run when you run molecule test? Or if you need to remove a step (e.g. for some very specialized use cases, you don't want to verify idempotence—the playbook is supposed to make a change on every run)?

The order of scenarios (in Molecule's terms) can be modified, along with just about everything else, in the molecule.yml file.

For the example above, since we don't need to install any dependencies or run a preparatory playbook, we can take those out by adding the following configuration, under the scenario top level configuration. Here's the default set of scenarios as of Molecule 2.19:

scenario:
  name: default
  test_sequence:
    - lint
    - destroy
    - dependency
    - syntax
    - create
    - prepare
    - converge
    - idempotence
    - side_effect
    - verify
    - destroy

Since we don't need certain steps, we can comment out:

  • dependency: If this role required other roles, we could add a requirements.yml file in the default scenario directory, and Molecule would install them in this step. But we don't have any requirements for this role.
  • prepare: You can create a prepare.yml playbook in the default scenario directory and have Molecule run it during the prepare step, but we don't need one for this role.
  • side_effect: You can create a side_effect.yml playbook in the default scenario directory and have Molecule run it during the prepare step, but we don't need one for this role.

So now our scenario definition looks like:

scenario:
  name: default
  test_sequence:
    - lint
    - destroy
    # - dependency
    - syntax
    - create
    # - prepare
    - converge
    - idempotence
    # - side_effect
    - verify
    - destroy

And if we run molecule test, we won't see all the notices about skipped actions, because they're not in the test_sequence.

There are many other things you can configure in molecule.yml; in fact, pretty much every setting and option in Molecule is configurable or overridable. See the Molecule configuration documentation for all the gory details.

Use pre-built Docker images with Molecule

Speaking of things you can configure in molecule.yml—if you want to speed up your test runs (especially in ephemeral CI environments), you can swap out the default Docker build configuration for your own Docker image, and tell Molecule you've already configured the image with Ansible.

And wouldn't you know, I already maintain a number of base Docker images with Ansible pre-installed, for most popular Linux distributions:

All of the above base images have not only Ansible, but also systemd (or sysvinit in older Ubuntu and CentOS releases), so you can test service management, and pretty much anything you'd be able to test in a full-fledged virtual machine.

To use those images, I customize my molecule.yml file's platforms configuration a bit:

platforms:
  - name: instance
    image: "geerlingguy/docker-${MOLECULE_DISTRO:-centos7}-ansible:latest"
    command: ${MOLECULE_DOCKER_COMMAND:-""}
    volumes:
      - /sys/fs/cgroup:/sys/fs/cgroup:ro
    privileged: true
    pre_build_image: true

Many of the options, like volumes, command, image, and privileged are passed through exactly like you'd expect from a Docker Compose file, or in the Ansible docker_container module's parameters. The special pre_build_image option, when set to true, means that the image you're using already has Ansible inside, so Molecule doesn't need to waste time building it if the image doesn't exist locally.

You might also notice my use of variables like ${MOLECULE_DISTRO:-centos7}; Molecule conveniently supports environment variables inside the molecule.yml file, and you can even provide defaults like I have with the :-centos7 syntax (this means that if MOLECULE_DISTRO is an empty string or not set, it will default to centos7).

So when I run molecule commands, I can run them with whatever OS I like, for example:

MOLECULE_DISTRO=ubuntu1804 molecule test

This will run the test suite inside an Ubuntu 18.04 environment. If I don't set MOLECULE_DISTRO, it will run inside a CentOS 7 environment.

I also use use volumes to mount /sys/fs/cgroup inside the image, and set the --privileged flag, because without these, systemd won't run correctly inside the container. If your Ansible roles aren't managing services using systemd, you might not need to use those options (even if you use my Docker images); many Ansible playbooks and roles work just fine without the elevated Docker container privileges.

You don't have to use your own pre-built images (or mine), but if you have the tests run in Travis CI or any other environments where Docker images are not persistent (heck, I run docker system prune --all on my local workstation all the time!), it's much faster to use pre-built images. Plus you can have images which simulate a more full VM-like experience.

If you use VirtualBox, EC2, or some other platform, then the amount of time and effort required to maintain a custom image might negate the minimal performance gain from pre-building the images; but at least the option is out there. Oh, and I have plenty of Vagrant base image builds for VirtualBox (built automatically with Packer and Ansible) you could use to get started (e.g. packer-ubuntu-1804)!

Integrating Molecule into Travis CI

The holy grail, at least for me, is reproducing my entire multi-os testing platform I've built up over the years using Molecule instead of some cobbled-together shell scripts. One reason I am able to maintain nearly 100 popular Ansible roles on Ansible Galaxy (and lots of other projects besides) is the fact that all the common usage scenarios are thoroughly and automatically tested—not only on every pull request and commit, but also on a weekly cron schedule—via Travis CI.

I won't go into the full details of how I switched from my old setup to Molecule in Travis CI, but I will offer a couple examples you can look at to see how I did it, and managed to make a maintainable test setup for multiple operating systems and playbook test cases using Molecule and Travis CI:

  • geerlingguy.kibana (Travis CI build) - This is one of the simpler test cases; it just tests on two distros, the latest version of Ubuntu and CentOS, and runs one playbook which installs Kibana then makes sure it's reachable.
  • geerlingguy.jenkins (Travis CI build) - This is one of my most complicated roles, therefore it has much a more complex array of tests. Not only is it tested against four different distros, there are also five separate test playbooks used to test various common use cases and configurable options.

In the Jenkins role (and many others), I specify a different MOLECULE_PLAYBOOK for the converge playbook. Some people may prefer an entirely different molecule scenario (besides the default scenario) for different test cases, but in my case, I set the converge playbook name (provisioner.playbooks.converge in the molecule.yml) to an environment variable so I can use a different playbook per scenario:

provisioner:
  name: ansible
  lint:
    name: ansible-lint
  playbooks:
    converge: ${MOLECULE_PLAYBOOK:-playbook.yml}

In all my roles, I use Travis CI's build matrix feature to perform each distro/playbook combination test in a separate build container, running in parallel with the other tests. It would take 7x longer to run all the Jenkins tests in series, and I hate waiting to see if a pull request will break anything in my role!

Dive Deeper into Ansible role and playbook testing

You can find out even more about Molecule, Travis CI, Docker integration, and other testing topics in my book, Ansible for DevOps.

Comments

Molecule sounds cool and all, but will it support roles intended for multiple environments, including un-Dockerable platforms like macOS? https://github.com/mcandre/ansible-curl

For macOS role testing, I still use Travis CI's native macOS build support—see, for example, my geerlingguy.mas role.

I haven't tested it, but it could be possible to use Molecule with a macOS VirtualBox image. It's not very fun to get working though—Apple doesn't really give a lot of support to running macOS in virtualized environments :(

Hey Jeff, a couple months a go I had a crack at porting your home brew and Elliot’s commandline tools roles to Travis. It ended up working pretty well but it took a very long time to run, the main issue was that I needed to manually recompile Ruby because of the brew links when uninstalling the already installed hombrew and commandline tools. I don’t know if that’s needed anymore. I think I attempted MAS locally but I had issues with my OSX version, but MAS shouldn’t need ruby compiling because it’s just a brew package. My GitHub link for the home brew role is
: https://github.com/audibailey/ansible-homebrew-role
The Travis link is:
https://travis-ci.org/audibailey/ansible-homebrew-role

I didn’t try the vagrant option for OSX but I’m thinking the overall run time would take longer because it needs to download a 14GB+ packer OSX image.

Anyways, thanks for you work and hopefully this helps.

Regards,
Audi Bailey

I've been using Molecule for Ansible testing since I was fortunate enough to be in the room for this talk at AnsibleFest 2017.

https://www.ansible.com/infrastructure-testing-with-molecule

It's quite flexible in what you target for machines, and for one integration test that required a lot of resources, I used the Delegated driver to defer the infrastructure setup to Terraform, and then used the Terraform module for Ansible to provision from the terraform template. Since Terraform accepts JSON configuration files, the playbook was able to assemble the infrastructure using a series or set-facts and then pipe and object to JSON and store it in a file. As Proof-of-Concepts go, it was pretty ugly, but with a couple filter plugins the whole thing could have been made very elegantly.

Just remember that version presented at Ansible fest were of Molecule v1 and not very relevant today.

just a quick note to add to your article. One very nice feature of Molecule when testing with Docker is the `--destroy-never` flag (`molecule test --destroy never`). It allows not to destroy the container upon failure. Which allows to inspect the state of the container after the failure. This is particularly useful when debugging testinfra tests.

I used to use molecule before. At some point it started to crash my Ubuntu workstation. This is due to running systemd in a container and `--privileged`. So the systemd in docker was actually communicating to the outside which freaked my workstation out. I consider this a very unsafe practice. Especially, if you use roles of other people.

https://github.com/ansible/molecule/issues/1102
https://github.com/ansible/molecule/issues/1104

Therefore, I actually switched back to you shim. Do you have any idea how to do this in a better way?

In many cases, if you're not managing services inside Docker containers, you can just not use privileged, and it will work fine. I only use it because in a few cases my roles don't build correctly without it. But I should really default to off and only turn it on for the roles that actually need it...

Also, you can use VirtualBox instead if you want (or one of the other providers supported by Molecule).

Thanks again for the article. Using the TravisCI matrix is a nice trick to speed up the testing. Caching the pip dependencies saves another 40 seconds for me.
```
# .travis.yml
language: python
cache: pip
```

I get the following errors. My setup is a macbook pro.

--> Action: 'destroy'

    PLAY [Destroy] *****************************************************************

    TASK [Destroy molecule instance(s)] ********************************************
    changed: [localhost] => (item=None)
    changed: [localhost]

    TASK [Wait for instance(s) deletion to complete] *******************************
    failed: [localhost] (item=None) => {"attempts": 1, "censored": "the output has been hidden due to the fact that 'no_log: true' was specified for this result", "changed": false}
    fatal: [localhost]: FAILED! => {"censored": "the output has been hidden due to the fact that 'no_log: true' was specified for this result", "changed": false}

    PLAY RECAP *********************************************************************
    localhost                  : ok=1    changed=1    unreachable=0    failed=1


ERROR:
An error occurred during the test sequence action: 'destroy'. Cleaning up.
--> Scenario: 'default'
--> Action: 'destroy'

    PLAY [Destroy] *****************************************************************

    TASK [Destroy molecule instance(s)] ********************************************
    changed: [localhost] => (item=None)
    changed: [localhost]

    TASK [Wait for instance(s) deletion to complete] *******************************
    failed: [localhost] (item=None) => {"attempts": 1, "censored": "the output has been hidden due to the fact that 'no_log: true' was specified for this result", "changed": false}
    fatal: [localhost]: FAILED! => {"censored": "the output has been hidden due to the fact that 'no_log: true' was specified for this result", "changed": false}

    PLAY RECAP *********************************************************************
    localhost                  : ok=1    changed=1    unreachable=0    failed=1


ERROR:

It looks like Molecule is having trouble deleting the Docker instance used for your testing. Is Docker running on your Mac? If you run docker ps do you see any running containers?
